Upgrade your garage with PRO Series features. This model includes curb appeal upgrades like eaves on all four walls and high definition/high impact dimensional shingles which match more closely a typical residential roof line. Concrete is required but not included in the price.
*Buildings shown here with optional upgrades. Availability of specific upgrades may vary by region.
Slide 1 of 6
| Feature | Specification |
|---|---|
| Warranty | 10-year limited warranty on workmanship & materials |
| Concrete | Required, but not included in price |
Slide 1 of 6
| Feature | Specification |
|---|---|
| Warranty | 10-year limited warranty on workmanship & materials |
| Concrete | Required, but not included in price |
| Bottom Plate | 2 x 4 pressure treated lumber |
| Bottom Plate | 2 x 4 pressure treated lumber |
| Door Type and Size | 3'x6'8" 6-panel residential door |
| Door Type and Size | 3'x6'8" 6-panel residential door |
| Door Hardware | Locking handset and deadbolt |
| Door Hardware | Locking handset and deadbolt |
| Aluminum Threshold at Door | Residential door threshold included |
| Aluminum Threshold at Door | Residential door threshold included |
| Interior Clear Sidewall Height | 8'1" measured from concrete to top of top plate |
| Interior Clear Sidewall Height | 8'1" measured from concrete to top of top plate |
| Wall Framing | 2 x 4 studs spaced 16" on-center plus extra corner stud |
| Wall Framing | 2 x 4 studs spaced 16" on-center plus extra corner stud |
| 2 x 4 Wall Top Plates | Double top plates on all walls |
| 2 x 4 Wall Top Plates | Double top plates on all walls |
| Siding Type | LP® SmartSide® with SilverTech® radiant barrier & 50-Year warranty |
| Siding Type | LP® SmartSide® with SilverTech® radiant barrier & 50-Year warranty |
| Trim Type | LP® Smart Trim w/50-Year warranty |
| Trim Type | LP® Smart Trim w/50-Year warranty |
| Roof Type | Gable (ranch) style |
| Roof Type | Gable (ranch) style |
| Roof Pitch at Peak | (5/12) |
| Roof Pitch at Peak | (5/12) |
| GAF Shingles | HDZ dimensional shingles w/ impact rating & lifetime limited warranty |
| GAF Shingles | HDZ dimensional shingles w/ impact rating & lifetime limited warranty |
| Roof Decking | 7/16" LP® SilverTech® radiant barrier roof decking |
| Roof Decking | 7/16" LP® SilverTech® radiant barrier roof decking |
| Rafters and Trusses | 2 x 4 trusses w/ steel plates |
| Rafters and Trusses | 2 x 4 trusses w/ steel plates |
| Colored, Baked Enamel Drip Edge | Included on perimeter of roof |
| Colored, Baked Enamel Drip Edge | Included on perimeter of roof |
| Roofing Underlayment | Moisture barrier underlayment included |
| Roofing Underlayment | Moisture barrier underlayment included |
| Eave Type | 12" soffited sidewall and endwall eaves |
| Eave Type | 12" soffited sidewall and endwall eaves |
| On-Site Installation | Included in price |
| On-Site Installation | Included in price |
